Product Description

M8 Conical Spring Washers (DIN 6796) - A2 Stainless Steel

Conical Spring Washers, also known as Belleville Washers; are a cone shaped washer, designed to prevent loosening of bolted joints and to act as a spring. These are designed to be flexible and to create accurate concentric force dispersal. These washers were made to be able to support high loads with minimal deflection.

These Conical Spring Washers are made from A2 Stainless Steel which provides corrosion and oxidation resistance.

For larger quantities or items not listed, please email sales@gwr-fasteners.co.uk and one of our team will provide you with a quotation.

Read More

Specifications

Nominal Inside Diameter
M8
Inside Diameter
8.4mm
Outside Diameter
18mm
Thickness
2mm
Uncompressed Height
2.6mm
Manufacturing Standard
DIN 6796
Material
Stainless Steel (A2)
Finish
Natural
Product Code
A2-CON-M8

Customer Reviews

M8 Conical Spring / Belleville Washers (DIN 6796) - A2 Stainless Steel

Item in Stock (368 Available)

Product Code A2-CON-M8

Need more?

0 : 1 - 2 Working Days

114,800 : 3 Weeks
